Process Instrumentation
Process Instrumentation measures the physical state of the process (Pressure, Temperature, Level, Flow) and is the fundamental input used in process measurement and control systems. The accuracy and reliability of Process Instrumentation has a direct and critical input on the quality, efficiency and safety of the plant.
Swagelok products are used in many applications to control and isolate process fluids which are measured by process instrumentation.
Few of our Solutions for Process Instrumentation include:
Instrument Enclosures
We build assemblies considering your operating environment and account for factors such as vibration, temperature extremes, and the accessibility of devices. Locally assembled Instrument Enclosures and Kits minimizes your field repairs and reduces losses. These enclosures are certified with Swagelok limited lifetime warranty.
Manifolds
Swagelok offers wafer, traditional, compact designs in 2-, 3-, 4-, and 5-valve manifold configurations with 316 SS standard; 625, 254, 2507, Monel, Hastelloy materials.
Process Interface Valves
Swagelok process interface valves (DBBs - Double Block and Bleed) offer fewer Leak points, smaller compact design, weight reduction of up to 75%, Reduced Installation time, reduced vibration stress, reduced fugitive emissions and integral Swagelok Tube Fitting (option on outlet and vent. We offer VB03 (three-piece B/N/B), VB04 (one-piece B/N/B), VB05 (one-piece Fugitive Emissions B/N/B), MN0 (Mono-flanges), VN0 (N/N/N including HPHT ) and VB0451 (Metal-Seated B/N/B).
Flange Adapters and Tube Plugs
Thread-less , weld-less transition fitting from process piping to Swagelok tube fitting or NPT.
FK Series Products
FK Series Products were developed by Swagelok and leverage the two-ferrule fitting connection design with patented technology, similar to the Swagelok Tube Fitting. This fitting design provides excellent vibration resistance and leak tight gas seal. These products include fittings, FKB series ball valve and tubing. Pressure rating is up to 20ksi. Sizes 1/4 to 3/4 inch. These products use true OD tubing.
IPT Series Products
IPT Series Products were acquired in 2012 from Innovative Pressure Technologies (IPT) and provides cone and thread connection technology that is typically used in hydraulic applications. Cone and thread is interchangeable with other manufacturers due to the open architecture design. Product range includes fittings, ball valves, needle valves, check valves, relief valves and block and bleed valves, as well as, tubing. Pressure range is 20ksi to 60ksi, sizes 1/4 to 1 1/2 inch. These products use nominal OD tubing.
Sno-Trik Products
FK Series Products were developed by Swagelok and leverage the two-ferrule fitting connection design with patented technology, similar to the Swagelok Tube Fitting. This fitting design provides excellent vibration resistance and leak tight gas seal. These products include fittings, FKB series ball valve and tubing. Pressure rating is up to 20ksi. Sizes 1/4 to 3/4 inch. These products use true OD tubing.
